SKF SONL 222-522 Split plummer block housings, SONL series for bearings on an adapter sleeve

Place of Origin:
Original SKF
Brand Name:
SKF
Certification:
Original certificate
Model Number:

SKF SONL 222-522 Split plummer block housings, SONL series for bearings on an adapter sleeve

Min.Order Quantity:
One set SKF SONL 222-522 Split plummer block housings, SONL series for bearings on an adapter sleeve
Price:
Contact with us
Packaging Details:
Usual packing free
Delivery Time:
Within 4 working days
Payment Terms:
paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
Supply Ability:
160
Contact Now


Product Description

SKF SONL 222-522 Split plummer block housings, SONL series for bearings on an adapter sleeve
Split plummer block housings, SONL series for bearings on an adapter sleeve

Bearing (basic designation) C 2222 K
Adapter sleeve HA 322 E
Locating ring 2 x FRB 9/200
Dimensions
da 100.013mm
Ca 71mm
Da 200mm
A 213mm
A1 145mm
A2 163mm
AA 221mm
AB 229mm
d1 120mm
B1 88mm
H 290mm
H0 343mm
H1 160mm
H2 50mm
J 347mm
J1 75mm
L 420mm
N 32mm
N1 26mm
S 114.5mm
Shaft end
ba 52mm
bb 167mm
s2 32.5mm
Dowel pins
J6 370mm
N4max.8mm
Circulating oil lubrication system
PG G 3/8
P1 55mm
P2 53mm
RG G 3/4
R1 162mm
R2 23mm
O1 98mm
O2 163mm
Appropriate seals and end cover
Seal kit for a through shaft TSO 522/3.15/16
Seal kit for a shaft end TSO 522/3.15/16 A
End cover ECO 222-522
Breaking loads, housing
P55° 1260kN
P90° 500kN
P120° 350kN
P150° 320kN
P180° 420kN
Pa 170kN
Yield point, cap bolts
Q120° 440kN
Q150° 250kN
Q180° 220kN
Mass
Mass housing 53kg
Mounting information
Cap bolt, size M 12x90
Cap bolt, rec. tightening torque 80N·m
Appropriate attachment bolt, sizeG 24mm
Appropriate attachment bolt, rec. tightening torque 665N·m
Eye bolt, size M 12
Oil level, min. 53mm
Oil fill, min. 0.6l
Oil level, max. 77mm
Oil fill, max. 0.9l
